KIN IC62

$0.00

Artistic Truth

The IC62 is Totem’s premium 6.5” in-ceiling speaker in the KIN Architectural IC series.

The refinement of the IC62 expresses Totem’s mission is to develop loudspeakers capable of producing an involving performance that is true to the artist’s intention. They energize the area in manner that faithfully recreates the intimate moment and space of the original recording, yet disappear into the environment.

Exclusive MHEX Phenolic Honeycomb Woven Hybrid woofers in cast baskets synergize perfectly with customized ceramic dome tweeters to provide our characteristic phase linearity and unmatched realism. Dynamics are maintained at any listening level for all acoustic preferences or applications, from a high-powered home theater to low level ambient music.

Kin Architectural models have stainless steel, magnetic grilles and hardware so they’re weather resistant and ready for the outdoors under covered areas and soffits with the use of the optional Acoustic Back Can.

Discover your Kin Architectural and expand your musical experiences.

Optional Accessories

  • PCK6: Pre-construction kits facilitate installation before drywall has been installed.
  • ABC6: Acoustic Back Cans reduce sound from penetrating adjacent rooms, protects the components from damage causing materials, and improves the weather resistance.
  • SGK6: Square Grille Kits permit cosmetic finishing touches to suit personal design tastes.



  • High-torque, Nylon dogs which can accommodate double layers of drywall
  • 75-degree dispersion
  • Unified framework shield
  • Paintable neodymium-activated stainless-steel grills
  • Stainless steel, weather resistant hardware
  • Shallow profile
  • MHEX Phenolic Honeycomb Woven Hybrid woofer
  • Cast baskets and oversized components
  • 1” Ceramic coated aluminum dome tweeters
  • Low Volume Intelligibility equalization
  • Gold-plated terminals
  • High-torque, Nylon dogs which can accommodate double layers of drywall
  • 75-degree dispersion
  • Unified framework shield
  • Paintable neodymium-activated stainless-steel grills
  • Stainless steel, weather resistant hardware
  • Shallow profile
  • MHEX Phenolic Honeycomb Woven Hybrid woofer
  • Cast baskets and oversized components
  • 1” Ceramic coated aluminum dome tweeters
  • Low Volume Intelligibility equalization
  • Gold-plated terminals
Design: 6.5″ In-Ceiling with with LVI equalization switch
Frequency Response: 46 Hz – 30 kHz
Recommended Power: 20-110 W
Woofer: 6.5” MHEX Phenolic Honeycomb Woven Hybrid woofer in die-cast basket
Tweeter: 1” Ceramic coated aluminum dome tweeter
Impedance: 8 ohm
Sensitivity  (dB @1W-1M): 90dB
Dimensions (w x h x d): 234 x 120.65mm /  9.21 x 4.75″   With back can:  157.41 /6.19″
Cutout: 211mm
Grille Type: magnetic, paintable, virtually bezel-less white metal
Accessories / Options: Pre-construction brackets, square grilles, acoustic back can
Speaker Terminals: Spring loaded Gold Plated
Weight: 4.8lb / 2.18kg

Description

Exquisite Sound. Out of Sight.

High-end In-Ceiling Sound Experience.







Easy Installation.







Round or Square, Paintable Grills.







Pivoting Tweeter Faceplate.

Features in Detail
